Product Description
Noble Refinish automotive spray booth aims to promote the efficiency of the workshop and enlarge the profits for our customer. For this purpose, we must achieve the fastest drying time, the lowest operation costs and as little environment impact as possible.
Automobile spray booth is a closed environment for vehicles painting and baking in a body shop with pressure control. In order to provide an ideal working condition, this environment should be equipped with one or several groups of ventilation and burners to heat the air to ensure the automotive spray booth has suitable temperature, air flow and illumination.
Advantages
This JC-600 car spray booth is designed with numerous special details, considering the actual needs of the demanding clients. It is safe and eco-friendly, due to the adoption of high-class configurations. As our luxurious type product, this product is basically applicable for the high-end brand car 4S shops and high-level repair factories.
Noble Refinish car spray booth is designed with the paint-spray mist filtering equipment without a pump, for fully mixing the paint mist, water and air. In this way, the paint mist can be effectively decreased to over 98%. The inconvenience resulted from the replacement of the dry filter is also reduced. Moreover, the exhaust gas conforms to the national standard.
Furthermore, the car spray booth is equipped with the dual temperature-protection system, the electronic temperature controller, and the high-quality mechanical temperature controller. When the temperature in the chamber exceeds standard, the sound-light alarm will display information, and automatically cut power off.
Characteristics
· The motors are ABB brand
· The cabin structure is a shape of 凸, The roof adopts European style convex top net with hinges, which is easy to install and beautiful.
· Due to the adoption of RG5S type burner, the heating capacity can reach 260,000Kcal/h, and the heat-up time is shortened.
· Moreover, our car spray booth is configured with a set of electric damper and a set of manually-operated louver damper.
Main Specification
| Model No. | JC-600 Spray Booth |
| Room Size | |
| Inner Size | 7000×4000×2800 mm(L×W×H) |
| Outer Size | 7100×5950×3600 mm(L×W×H) |
| Basement | |
| Basement | Galvanized sheet bending base, height 300mm. All-round grille floor, with deflector. |
| Grilles’ Loading capacity | 600 kg/single wheel |
| Filter surface area | 28㎡ |
| Grill | 768×998×30mm(L×W×H), It is welded by 30×4mm flat steel + D8 twisted steel and galvanized. |
| Floor Filter | G2 Grade fiberglass filter |
| Ramp | 2 ramps,size:2000x750mm(LxW) |
| Cabin | |
| Cabin Structure | Shape of 凸 |
| Plenum height | 500mm |
| Wall Panel | Insulation mechanism rockwool foam board 50mm total thickness, substrate 0.426mm color steel plate, density: 100kg/m³ |
| Roof | The roof adopts European style convex top net with hinges, which is easy to install and beautiful. |
| Roof panel | 0.7mm Galvanized panel |
| Cover Material | 1.0mm Bending and forming of galvanized sheet, the surface is sprayed white. |
| Main Door | |
| Main Door | Four-leaf Main door |
| Size | 3200×2600 mm(W×H) |
| Arrangement | 1 set for car’s entrance and exit |
| Structure | Handmade sheet metal gate with glass observation window, 5mm tempered glass, aluminum alloy frame |
| Personnel Door | |
| Personnel Door | Aluminum frame personnel door |
| Size | 800×2000 mm (W×H) |
| Arrangement | 1 pc |
| Structure | Manual door leaf, glass observation window, with pressure door lock |
| Top Lighting | |
| Qty and power | 8 sets of light boxes, each set of 4×20W,LED , total 640W |
| Arrangement | Two rows of ceiling lights are distributed on both sides of the top of the house. |
| Special | |
| Side Lighting | |
| Qty and power | 8 sets of light boxes, each set of 4×20W,LED , total 640W |
| Arrangement | Two rows of side lights are distributed on both sides of the wall panel of the house. |
| Special | Open light box inside design, integral glass cover |
| Description | LED tube,lux：1900lm |
| Total flux: | >1400Lux |
| Filter System | |
| Intake pre-filter | Bag filter G3 class. |
| Ceiling Filter | F5 grade filter , model 600G filter |
| Base paint filter | Bottom G2 Grade Fiberglass Paint Resistant |
| Exhaust filter | Bag type activated carbon filter G3 grade |
| Inlet System | |
| Fan Type | Direct-connect type Turbo fan |
| Motor | 7.5KW,1450 rpm, 380 V, 50 Hz ABB brand Motor |
| Fan info | Model:DDF-630B,air capacity:28000-30000m³/h,pressure: 600pa |
| Diesel Heating system | |
| Heat exchanger material | δ1.5mm stainless 1Gr18Ni9Ti（SUS304） |
| Heat exchanger | 232 KW |
| △T | 25°C(from 0°C to 25°C in painting status) |
| Max.working temperature | 80°C |
| Rising temperature time | 8-10mins (from 20° to 60°ºС) in baking status |
| Burner | Italy burner,Model:RG5S,capacity:260k Kcal/h |
| Outlet System | |
| Fan type | Direct-connect type Turbo fan |
| Motor | 7.5KW,1450 rpm, 380 V, 50 Hz ,ABB brand Motor |
| Fan info | Model:DDF-630B,air capacity:28000-30000m³/h,pressure: 600pa |
| Air speed | 0.27m/s |
| Noise | Less than 80db |
| Duct System | |
| Intake duct | 2pcs 700×700×1000mm straight duct,1pc air intake hat |
| Exhaust duct | 3pcs 700×700×1000mm straight duct,1pc exhaust gravity damper |
| Damper | 2 pcs manual damper,one for intake,one for exhaust. |
| Control System | |
| Safety system | Over-temperature alarm shutdown function, room pressure protection, fault alarm, external indicator light, emergency stop |
| Control panel | Painting, raising temperature painting, baking , drying time setting, lighting switch, fault indicator, temperature controller, power switch, emergency stop switch, timer, pressure gauge |
| others | CE standard connecting cables, junction boxes, conduits and accessories |
